APC Smart-UPS 1500VA, 1000W LCD 230V with SmartConnect

Out of stock

SKU: SMT1500IC Categories: , Tag:

    Please fill in your details to enquire about this product

    Please prove you are human by selecting the plane.

    Output
    Max Configurable Power (Watts)
    1.0kWatts / 1.5kVA
    Output Voltage Note
    Configurable for 220 : 230 or 240 nominal output voltage
    Output Voltage Distortion
    Less than 5 %
    Output Frequency (sync to mains)
    50/60 Hz +/- 3 Hz Sync to mains
    Other Output Voltages
    220 V, 240 V
    Topology
    Line interactive
    Waveform type
    Sine wave
    Transfer Time
    6 ms typical : 10 ms maximum
    Input
    Input frequency
    50/60 Hz +/- 3 Hz Auto-sensing
    Input voltage range for main operations
    151 – 302 Adjustable, 160 – 286V
    Number of Power Cords
    1
    Other Input Voltages
    220 V, 240 V
    Batteries & Runtime
    Battery type
    Lead-acid battery
    Typical recharge time
    3hour(s)
    Replacement Battery
    RBC7
    Expected Battery Life (years)
    3 – 5
    RBC Quantity
    1
    Battery Charge Power (Watts)
    136 Watts
    Runtime
    View Runtime Graph
    Efficiency
    View Efficiency Graph
    Communications & Management
    Interface Port(s)
    SmartSlot, USB
    Control panel
    Multifunction LCD status and control console
    Audible Alarm
    Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
    Available SmartSlot™ Interface Quantity
    1
    Surge Protection and Filtering
    Surge energy rating
    459Joules
    Filtering
    Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
    Physical
    Maximum Height
    219MM, 21.9CM
    Maximum Width
    171MM, 17.1CM
    Maximum Depth
    439MM, 43.9CM
    Net Weight
    24.09KG
    Shipping weight
    27.23KG
    Shipping Height
    376MM, 37.6CM
    Shipping Width
    328MM, 32.8CM
    Shipping Depth
    595MM, 59.5CM
    Color
    Black
    Units per Pallet
    12.0
    Environmental
    Operating Temperature
    0 – 40 °C
    Operating Relative Humidity
    0 – 95 %
    Operating Elevation
    0 – 3048meters
    Storage Temperature
    -15 – 45 °C
    Storage Relative Humidity
    0 – 95 %
    Storage Elevation
    0 – 15240meters
    Audible noise at 1 meter from surface of unit
    45.0dBA
    Online thermal dissipation
    90.0BTU/hr
    Conformance
    Approvals
    CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE
    Standard warranty
    3 years repair or replace (excluding battery) and 2 years for battery
    Sustainable Offer Status
    RoHS
    Compliant
