AOC 20E1H 19.5″ HD+ 60Hz 5ms TN Desktop Monitor with HDMI & VGA (20E1H)
The AOC 20E1H 19.5″ HD+ Monitor (20E1H) provides reliable daily performance and clear visuals for compact home and office setups. Features a 1600×900 HD+ resolution TN panel, 5ms GTG response time, 100% sRGB color gamut, low 12W power draw, VESA mount compatibility, and dual HDMI/VGA connectivity.
- Display & Panel: 19.5″ HD+ (1600 x 900) 16:9 TN Panel | 600:1 Contrast | 100% sRGB
- Speed & Performance: 60Hz Refresh Rate | 5ms (GtG) Response Time
- Connectivity: 1x HDMI 1.4 | 1x VGA | Audio In & Headphone Out
- Mounting & Ergonomics: VESA Mountable (100 x 100 mm) | Tilt Adjustment (-3.5° to 21.5°)
- Warranty: 3-Year Carry-in Warranty
Streamline your everyday workstation with the AOC 20E1H 19.5-inch HD+ Desktop Monitor. Designed for compact work environments, home offices, and essential computing, this sleek display offers crisp 1600×900 resolution, a responsive 5ms GTG response time, and flexible dual HDMI and VGA connectivity. Featuring VESA wall-mount compatibility, tilt adjustment, and low power consumption, the 20E1H delivers dependable visual clarity and efficiency for daily administrative tasks.
Key Features
- Crisp HD+ Resolution: 1600 x 900 resolution on a 19.5-inch anti-glare TN panel ensures clear text rendering and detailed image viewing.
- Fast 5ms GTG Response Time: Reduces motion smear and ghosting during rapid scrolling and video playback.
- Rich Color Coverage: Supports 100% sRGB and 84% NTSC color gamut with 16.7 million display colors for vivid visuals.
- Versatile Dual Inputs: Equipped with HDMI 1.4 and VGA ports for seamless connections to laptops, desktop PCs, and media devices.
- Audio Line-Out Ports: Includes Audio In and a 3.5mm Headphone Out port for convenient external audio setups.
- Ergonomic & Mountable Design: Tilt-adjustable stand (-3.5° to 21.5°) and standard VESA 100x100mm wall-mounting support for clean desktop integration.
- Energy Efficient: Operates at an eco-friendly typical power consumption of just 12W.
Technical Specifications
| Display Size | 19.5-inch Viewable (49.5 cm) |
| Panel Type | TN (Twisted Nematic), Anti-Glare |
| Native Resolution | 1600 x 900 (HD+ @ 60 Hz) |
| Aspect Ratio | 16:9 |
| Pixel Pitch | 0.2712 mm (H) × 0.2712 mm (V) |
| Brightness | 200 cd/m² (Typical) |
| Static Contrast Ratio | 600:1 (Typical) |
| Dynamic Contrast Ratio | 20,000,000:1 (DCR) |
| Color Gamut | 100% sRGB (CIE1931) / 84% NTSC (CIE1976) |
| Response Time | 5ms (Gray-to-Gray) |
| Viewing Angles | 90° Horizontal / 65° Vertical (CR > 10) |
| Video Inputs | 1x HDMI 1.4, 1x VGA (RGB Analog) |
| Audio Output | 1x Audio In, 1x Headphone Out (3.5mm) |
| Power Consumption | 12W Typical (100 – 240V, 50/60Hz) |
| Stand Adjustments | Tilt (-3.5° forward to +21.5° back) |
| VESA Mounting | 100 x 100 mm |
| Dimensions (with Stand) | 461.4 mm (W) x 199.4 mm (D) x 379.31 mm (H) |
| Product Weight | 2.35 kg (Net with Stand) |
| Cabinet Color | Black |
| Part Number / SKU | 20E1H |
| Warranty | 3-Year Carry-in Warranty |
What’s in the Box
- AOC 20E1H 19.5″ HD+ Monitor Panel
- Monitor Stand Base & Riser
- VGA Cable
- Power Cable
- User Documentation
